Stainless steel plate and frame filter

Short Description:

The sealing ring of medical and health grade can be used to clamp various thin and thick filter materials, and it is more suitable for the heat filtration of high temperature liquid materials such as beer, red wine, beverage, medicine, syrup, gelatin, tea beverage, grease, etc.


  • Filter size (mm): Filter sheets (pieces)
  • BASB400UN-2 400*400: 3
  • BASB400UN-2 400*400: 6
  • BASB400UN-2 400*400: 9.5
  • BASB600NN-2 600*600: 40
  • BASB600NN-2 600*600: 70
  • BASB600NN-2 600*600: 100
  • Product Detail

    Product Tags

    Download

     Stainless steel plate and frame filter

    Stainless steel plate and frame filter

    The stainless steel plate and frame filter is made of stainless steel with high temperature resistance. The internal and external surfaces are polished with sanitary grade. The plate and frame is sealed without dripping and leakage, and the channel is smooth without dead angle, which ensures the effect of filtration, cleaning and sterilization. The sealing ring of medical and health grade can be used to clamp various thin and thick filter materials, and it is more suitable for the heat filtration of high temperature liquid materials such as beer, red wine, beverage, medicine, syrup, gelatin, tea beverage, grease, etc.

    Filter effect comparison

    application1

    Specific Advantages

    The BASB600NN is a high precision stainless steel plate and frame filter, High precision construction of the plate and frame assembly and hydraulic closing mechanism, combined with filter sheets, minimize drip-loss.

    * Minimized drip-loss
    * Precise construction
    * Applicable to a variety of filter media
    * Variable application options
    * Wide range of application
    * Efficient handling and good cleanability
    Beer wine plate and frame filter press machine
    Materials

    Rack
    Stainless steel 304
    Filter flate & frame
    Stainless steel 304 / 316L
    Gaskets / O-rings
    Silicone? Viton/EPDM
    Operating Conditions

    Operating temperature
    Max. 120 °C
    Operating pressure
    Max. 0.4 Mpa

    Technical data

    The above-mentioned date is the standard, it can customize according to customers requirements.

    Filter size (mm)

    Filter plate/Filter frame(Pieces) Filter area(M²) Cake framevolume (L) Reference filtration volume(t/h) Pump motor power(kW) Dimensions LxWxH (mm)
    BASB400NN-1
    400×400 21 3 22 1-3 1.5 1350x670x1400
    400×400 31 4 32 3-4 1.5 1550x670x1400
    400×400 45 6 46 4-6 1.5 1750x670x1400
    400×400 61 8 62 6-8 2.2 2100x670x1400
    400×400 71 9.5 72 8-10 2.2 2300x670x1400
    BASB600NN-2
    600×600 41 14 84 10-13 / 1750x870x1350
    600×600 61 21 124 15-20 / 2100x870x1350
    600×600 71 24 144 20-25 / 2250x870x1350
    600×600 101 35 204 25-30 / 2800x870x1350
    Stainless steel Rlate frame filter Application
